Auer Steel
Part #2-1/2B
Login for Price
1/4hp Brz Booster W/flgs 102220
Login for Price
- Bell & Gossett Booster Pump, 3-Piece, 1/4 hp, 115 VAC, 3 A, 60 Hz, 1 ph, 125 psi Maximum, 1725 rpm Motor, Centrifugal Impeller, 225 deg F, Sleeve Bearing, 17-1/4 in L x 10 in H
- Oil lubricated circulator
- Bronze body
- 115V With built-in overload protection
- Sleeve bearing, oil lubricated with replaceable resilient motor mounts
- Noise dampening coupler
- Bell & Gossetts own flexible spring design adds to quiet operation, do not accept a substitute
- Long bronze sleeve bearings maintain exact shaft alignment
- Provides for constant circulation of oil over bearing surfaces
- Precision ground pump shaft is oversized to provide large bearing surfaces
- Hardened integral thrust collar minimizes end-thrust to ensure long seal and bearing life
- The Bell & Gossett mechanical seal is designed to withstand the wide range of water temperatures, pressures, additives and dissolved solids common in hydronic systems
- Centrifugal impeller prevents accumulation of air at seal faces to assure long life
- Close impeller/body tolerances minimize water slippage and maximize efficiency
- Potable water is supplied
- 2-1/2 in NPT flange
- Model 2-1/2 AB
